Ultra-Low Freezer Monitoring
Swift Sensors ultra-low freezer monitoring keeps watch on every -80 °C freezer in your facility, day and night. A wireless sensor with a sealed ultra-low probe reads the cabinet continuously, logs every value to the Swift Sensors Cloud Console, and sends an instant alert the moment a freezer starts warming, while there is still time to move samples.
Let's Get Started
Ask a Question • Get a Quote • Request a Demo
ULT Freezer Monitoring, Alerts, and Records
An ultra-low temperature freezer holds the material a lab cannot replace: years of research samples, patient biospecimens, cell lines, reagents and ultra-cold vaccines. These units run hard at around -80 °C, and when one fails it rarely happens all at once. A compressor weakens, a door gasket ices over, a filter clogs, and the cabinet creeps upward over hours. A front-panel display and a local alarm only help if someone is standing in the freezer farm to see and hear them.
Swift Sensors ULT freezer monitoring puts that information in front of your team wherever they are. The SS3-110 sensor keeps its electronics outside the cabinet while a 1 m sealed probe reads inside, and a gateway sends each reading to the Swift Sensors Cloud Console. Set a threshold for every freezer, and instant alerts go out via email, SMS, or phone call as soon as a unit crosses it, at 3 a.m. as reliably as at noon. Every reading is stored automatically, giving you a continuous record for audits, sample chain-of-custody questions and conversations with your equipment service provider.
Because the system is wireless and battery-powered, it goes into an existing freezer room without new wiring or downtime, and it scales from a single ultra-low freezer to a full biorepository across several buildings.
Ultra-Low Monitoring Benefits
- Easy-To-Deploy Wireless Sensors
- Instant Critical Mobile Alerts
- Enterprise Cloud Monitoring Software
- Low-Cost Straightforward Monitoring Plan
- Robust Analytics and Compliance Reports
Remote Monitoring
System Components
Protect Your Business & Your Reputation
Swift Sensors is an easy-to-deploy, scalable monitoring and alerts solution driven by wireless sensors. Send instant alerts via email, SMS, or phone call for events that require immediate corrective action. Protect your business and your reputation from avoidable downtime, loss of assets, and preventable regulatory challenges.
Exceptional Return on Investment
Weiss Medical saved thousands of dollars in medications when Swift Sensors alerted staff of a power failure. View case study.
Example: two refrigerators and a freezer
- $1,610 Year 1: Hardware, NIST Calibration, Monitoring Plan
- $775 Year 2: Annual NIST Calibration, Monitoring Plan
- $775 Year 3: Annual NIST Calibration, Monitoring Plan
Compare to potential expenses:
- Lost vaccines and medications
- Lost irreplaceable patient biosamples
- Lost accreditation and reputation
- Regulatory fines and resubmissions
- Time and labor for manual temperature logging
- Legal fees from lost materials or service disruptions
Ultra-Low Temperature Monitoring for Labs
Research Labs
University and research labs protect years of samples, cell lines and reagents with continuous readings and alerts on every -80 °C freezer they run.
Clinical Labs
Hospital and diagnostic laboratories keep patient specimens in range and hold a complete temperature record for inspections and accreditation reviews.
Pharma and Biotech
Pharmaceutical and biotech teams monitor ultra-cold products, reference standards and stability samples across multiple freezer rooms from one Cloud Console.
Blood Banks
Blood centers and transfusion services add ultra-low freezers holding long-term plasma or research samples to the same system that watches their refrigerators.
Best Wireless Sensor For Ultra-Low Freezers
Swift Sensors’ standard probes read down to -40 °C, so ultra-low storage needs its own sensor. The SS3-110 is Swift Sensors’ ultra-low freezer temperature monitor: a 1 m (3 ft) sealed probe measures from -100 °C to +32 °C with 0.35 °C accuracy and 0.01 °C precision, while the IP66-rated sensor body stays outside the cabinet. Readings are taken at an inspection rate you choose from 1 to 30 minutes, 5 minutes by default, and the sensor runs 6 to 8 years on two replaceable AAA lithium batteries. Add the SS-TB3 aluminum thermal buffer, rated from -196 °C to +125 °C, to smooth out brief swings when the door is opened. Thresholds, schedules and alerts are set per freezer in the Cloud Console.
NIST Calibration Services
Swift Sensors offers NIST Calibration services through an independent ANAB ISO 17025: 2017 accredited laboratory. Swift Sensors manages all calibration logistics prior to initial sensor delivery and ensures seamless annual calibration renewal.
Testimonials
FAQ
What temperature does an ultra-low freezer run at?
Most ultra-low freezers are set at or near -80 °C, which is why they are often called minus 80 freezers. The right setpoint and alarm limit for yours depend on what is stored and on your lab’s procedures. The SS3-110 reads down to -100 °C, so it covers the full working range of a mechanical ultra-low freezer with room to spare, and you set the alert threshold per unit in the Console.
Can a wireless sensor read inside a -80 °C freezer?
The electronics of a wireless sensor are not built to sit inside a -80 °C cabinet, and thick, insulated steel walls block radio signals. The SS3-110 solves both: the sensor body mounts outside the freezer, and only the 1 m sealed probe goes inside. The probe reads the cabinet, and the sensor transmits over Bluetooth 5 to a gateway up to 100 m away in line of sight, or 30 m non line of sight.
What is the difference between an ultra-low freezer data logger and monitoring?
An ultra-low freezer data logger records temperatures for later review, which documents a failure but does not prevent one. Swift Sensors logs every reading the same way, and it also sends instant alerts via email, SMS, or phone call the moment a freezer crosses its threshold. You get the record for your audit and the warning in time to move samples.
Is an ultra-low temperature freezer thermometer or built-in alarm enough?
A built-in display and alarm are important, but both work only for someone who is nearby. Most freezer failures that destroy samples happen overnight, on weekends or over holidays. Remote monitoring adds an independent sensor, a stored history, and alerts that reach the right people wherever they are, escalating to the next tier if nobody responds. The Console also alerts if a sensor or gateway stops reporting, so the freezer is watched even when the room is empty.
Can monitoring warn you before an ultra-low freezer fails?
Often, yes. Freezers usually decline before they fail: the cabinet takes longer to recover after the door is opened, the average temperature creeps upward, or readings start to swing. Because every reading is stored in the Cloud Console, those trends are visible over days and weeks, giving you a reason to schedule service before a failure. Swift Sensors reports the temperature; your equipment provider diagnoses the freezer.
Does the SS3-110 work in liquid nitrogen storage?
No. The SS3-110 measures down to -100 °C, which covers mechanical ultra-low freezers, and liquid nitrogen storage runs far colder. For LN2 and anything below -100 °C, Swift Sensors uses the SS3-117 wireless thermocouple adapter with a third-party T-type thermocouple probe, which brings those readings into the same Cloud Console with the same alerts and reports. The SS-TB3 aluminum thermal buffer is rated from -196 °C to +125 °C, so it can be used in liquid nitrogen as well.
How does the Swift Sensors system work?
A Swift Sensors system requires the purchase of at least one gateway, at least one sensor, and a monitoring plan.
- Swift Sensors wireless sensors measure temperature, humidity, door activity, water leaks and other critical conditions. Each sensor is smaller than a credit card and has battery life of 6-8 years. The sensor transmits data via Bluetooth 5 (BLE5) and connects to the gateway with a push of a button.
- The gateway receives data from each sensor and then transmits the data to the cloud console via local ethernet, WiFi, or cellular network (optional module). Each gateway supports up to 150 sensors within 100 m line of sight (30 m non line of sight).
- The monitoring plan is very simple. The fee is based on the number of sensors you deploy. You can pay monthly, annually, or multi-year. There are no contracts required. View real-time analytics, download compliance reports, and receive instant mobile alerts on any device.
What is the signal range of the sensors?
The sensor range is up to 100 m line of sight and 30 m non line of sight depending on the facility infrastructure and equipment located between the sensor and the gateway. The sensors use the BLE5 wireless communication protocol which allows signal transmission through doors and walls constructed of standard building materials.
What is the battery life of the sensors?
Each sensor uses two AAA lithium polymer batteries with an average lifespan of 6-8 years. Replacement batteries are readily available at hardware stores and various retail locations.
How does the monitoring plan work?
The monitoring plan is very simple. The fee is based on the number of sensors you deploy. You can pay monthly, annually, or multi-year. There are no contracts required.
What is the Swift Sensors Console?
The Swift Sensors Console is a robust cloud-based monitoring, alerts, and reporting platform viewable remotely on any device. The Console is used for hardware setup and system configuration. The Console presents analytics that provide trend analysis, historical documentation, compliance reporting, and deep insights into equipment performance, facility operations, and environmental conditions. The platform is customizable and adaptable to any industry with unparalleled ability to search, filter, sort and view critical measurement and performance data. Configurable instant alerts enable immediate corrective actions when significant events occur. Alerts can be sent to individuals or groups via SMS text, email, or voice.
What about system security?
The Swift Sensors monitoring, alerts, and reporting platform was developed and is maintained by industry experts with extensive experience in network security. Sensor to gateway communication utilizes BLE5 and 128-bit AES encryption. Gateway to cloud Console communication utilizes ethernet, WiFi, or cellular (optional module) and 256-bit AES encryption. Data is securely transmitted over Secure Sockets Layer (SSL) on port 443. The Swift Sensor network does not allow any outside communication. As a result, the Swift Sensor network is incredibly secure.
Can I buy just the sensors?
Swift Sensors only communicate with Swift Sensors gateways. Swift Sensors gateways only communicate with the Swift Sensors Console. The Swift Sensor network does not allow any outside communication. As a result, the Swift Sensor network is incredibly secure. The Swift Sensor Console, however, features a robust API which can be utilized to communicate with 3rd-party applications.
Insights, Innovations
and Installations
What is Ultra-Low Freezer Monitoring?
Ultra-low freezer monitoring is the continuous, automated tracking of temperature inside freezers that run at or near -80 °C. Instead of reading the front panel once a shift and writing it on a log sheet, a probe placed in the cabinet takes readings around the clock and sends them to a cloud platform. When the temperature moves past the limit you set, the system alerts your team by text, email or voice, and every reading is stored to build a complete record.
What an ultra-low monitoring system does
Reads the cabinet continuously
With a probe rated for -80 °C storage, not a general-purpose sensor.
Alerts the right people
By email, SMS, or phone call the moment a freezer crosses its threshold, escalating if nobody responds.
Logs every reading automatically
Replacing paper logs with a complete digital history and a Daily Extremes report of each freezer's minimum and maximum.
Shows trends over days and weeks
Such as slower recovery after door openings or a warming baseline.
Covers every freezer in one account
From a single lab to a multi-building freezer farm.
Installs without wiring
Using battery-powered wireless sensors in the rooms you already have.
Swift Sensors builds its ultra-low offering around the SS3-110 sensor and the Swift Sensors Cloud Console. You set a threshold and an alert list for each freezer, see every unit on one screen, attach corrective action notes to an alert, and pull up to 5 years of stored temperature history for an audit, an inspection, or a sample integrity question in seconds rather than hunting through binders. NIST Calibration through an ANAB ISO 17025:2017 accredited laboratory covers standard points from -50 °C to +150 °C, and a -80 °C point is available through an additional accredited lab.
Ultra-Low Temperature Freezer Maintenance Signals
An ultra-low temperature freezer works harder than any other cold storage unit in the building, and routine ultra-low temperature freezer maintenance is what keeps it running: clean condenser filters, ice-free door gaskets, enough clearance for airflow, and a service plan from the manufacturer or a qualified technician. Monitoring does not replace any of that. What it adds is evidence about how each freezer is really performing between service visits.
Signals worth watching in the Cloud Console
Slow recovery after door openings
If a freezer takes longer each week to get back to its setpoint, it is losing capacity.
A rising baseline
A cabinet that used to hold -80 °C and now sits a few degrees warmer is telling you something.
Wider swings
Larger peaks and dips than the unit’s usual pattern can point to a compressor or control problem.
Room conditions
Freezers in a hot room run harder. An SS3-101 ambient sensor shows whether the room is part of the problem.
Swift Sensors does not service or repair freezers. What monitoring gives you is time: an ultra-low temperature freezer repair call placed while the unit is still holding temperature, with the readings your technician needs to see, instead of an emergency move of every sample after it has failed.
Related Monitoring Solutions
See Swift Sensors on Your Ultra-Low Freezers
Share how many ultra-low freezers you need to cover. A Swift Sensors specialist will follow up with a quote, a walkthrough of the Cloud Console, or answers to your questions.
- Wireless sensors that install without running wire
- Alerts by email, SMS or phone call, with escalation
- Monitoring plan billed monthly, annually or multi-year, no contracts
- NIST calibration through an ANAB ISO 17025 accredited lab
Prefer to talk? Call 512-256-7552
